PowerBass XL Marine / Powersports Amplifier (800W RMS - Class D Monoblock)

XL-805DMX

The XL series was developed for the growing Power Sports market including UTV and Marine applications, where electronics must withstand harsh damp environments. The circuit boards have been conformal coated with a layer of transparent material that protects the parts against moisture, dust and extreme temperatures.

DESCRIPTION

• These ultra small weather resistant amplifiers are ideal for all types of outdoor audio applications such as motorcycles, golf carts and off road vehicles. But the small size also makes these amps a great choice anywhere space is a premium.
• Utilizing the latest Class D circuit design these amplifiers may be small on size but they are big on power and have a much lower current draw compared to other amplifiers with similar power output. The wrap around aluminum heatsink keeps everything running cool.
• Extremely versatile, each model gives you’re a choice of low level RCA input or 3.5mm (1/8") mini-pug Aux Input. The Aux Input allows for easy connection of portable devices such as an iPod, MP3 player or smartphone to become your source unit.

Features:

• IPX67 Water Resistant Sealed Design
• Aluminum Die-Cast end caps with integrated connectors
• High Efficiency Class D Design
• 1-OHM Stable Monoblock Amplifier
• International Rectifier® Chip Set
• Ultra Low Current Draw
• 4-Layer Copper Plated PCB
• Conformal Coated PC Board
• PWM MOSFET Power Supply
• Digital Sound Optimization Circuitry
• High Damping Control Circuit
• High Current Voltage Ripple Rejection Circuitry
• 3.5mm AUX Input
• Remote Soft Delay Turn On/Off Circuit
• Variable Low Pass Electronic Crossover
• Variable 18dB Bass Boost EQ
• Variable Gain Control
• Protection Circuit: Impedance Over-load, Speaker Short, Circuit, Thermal Overheating, and DC Output.
• Remote Gain Control Included

SPECIFICATIONS

• Peak Power: 1600 watts
• Output Power (14.4 V) @ 4 ohm: 350 watts x 1
• Output Power (14.4 V) @ 2 ohm: 500 watts x 1
• Output Power (14.4 V) @ 1 ohm: 800 watts x 1
• Please click here for additional information.
